Monogram ZGU486NDTSS 48" Professional Gas Rangetop with 6 Burners and Griddle

Model: ZGU486NDTSS
$10,624.85
  • Description
  • Features
  • Specifications
  • 48" Professional Rangetop 6 Burner, 2-15K BTU Stacked, 2-18K BTU Stacked, 2-23K BTU Dual Ring Burners and 18K Griddle, Electronic Ignition, Auto Re Ignition
  • Versatile Gas Burner Configuration
    Delivering exceptional cooking flexibility, the two 23,000-BTU multi-ring brass burners and dual-stack burners offer a range of heat settings, from gentle simmer to intense flame

    3-Piece Grates with Reversible Wok Feature
    Reversible grates are easy to clean and complement different culinary techniques, with a flat side for traditional cooking and contoured side that perfectly holds round-bottom woks

    Ring-Lit Knobs
    Delivering a modern approach to accent lighting, the rings illuminate to indicate when a burner is in use

    Solid Brass Blades on Precision Machined Knobs
    With an unmatched attention to detail, all knobs on the new Monogram Pro ranges and range tops come with solid brass accents

    Seamless Stainless Top Frame
    Meticulously crafted from one piece of stainless steel that covers the cooktop and control panel, this seamless and stylish surface is easy to clean and beautiful to look at

    Stainless and Aluminum-Clad Griddle Included
    This versatile griddle delivers 18,000 BTUs of cooking power, allowing fast and consistent heating across the entire cooking surface

    Stainless Steel, No-Mark Griddle/Grill Covers Included
    Stainless steel covers help to protect the rangetop and keep it looking pristine, and can also be used as a flat food-preparation surface when the rangetop is not in use

    LP Conversion Kit Included
    Designed to deliver a seamless conversion experience, this self-contained kit includes everything needed to convert a rangetop to liquid propane
  • FEATURES

    Cooktop Burner Type- 2 Sealed, Dual Ring 4 Sealed, Dual Flame Stacked (Removable Brass Accents)

    Ignition System- Electronic

    Automatic Re-Ignition- Yes

    Configuration- 6 Burners; Griddle

    Extra Low Simmer- All Burners - Adjustable

    Control Location- Upfront

    Griddle- 18,000-BTU Stainless Steel and Aluminum Clad Thermostatically-  Controlled

    Burner Indicator Light- Yes

    Cooktop Burner Grate Features- Porcelainized Cast Iron 3-Piece Reversible (Flat/Wok)-  Grates

    Fuel Type- Natural Gas (factory set)

    Lighting- LED Bullnose Task Lighting

    Removable Drip Tray Liners- (1) Beneath Griddle

    Stainless Steel- Grill / Griddle Covers 1

    APPEARANCE

    Color Appearance- Stainless Steel

    Control Knobs- Diecast Metallic (Included) Stainless Steel with Brass Accents

    Design Style- Statement Collection

    Installation- Side-by-Side

    WEIGHTS & DIMENSIONS

    Approximate Shipping Weight- 227 lb

    Cabinet Width- 48 in

    Net Weight- 171 lb

    Overall Depth- 27 1/2 in

    Overall Height- 8 1/2 in

    Overall Width- 47 7/8 in

    POWER / RATINGS

    Griddle BTU Rating (000's/BTU) - LP Gas- 16.0

    Griddle BTU Rating (000's/BTU) - Natural Gas- 18.0

    Top Burner BTU Rating - LP (000's BTU's)- (2) 21.0; (2) 15.0; (2) 10.0

    Top Burner BTU Rating - Nat. Gas (000's BTU's)- (2) 23.0; (2) 18.0; (2) 15.0

    Volts/Hertz/Amps 120v; 60Hz; 15A

    ACCESSORIES

    48" Monogram Knob Kit- ZXPR48KKTSS (SS, qty. 11)

    Bamboo Cuttingboard- UXPRCB

    Conversion Kit- Included - Nat. Gas to LP

    Factory-installed island backguard- yes

    High Altitude Kit- WB28K10553

    Optional Backguard- 30"-36" adjustable stainless steel backsplash with warming shelf (UXADBS48PSS)

    Reversible Griddle/Grill Accessory- UXPRRGG

    WARRANTY

    Parts Warranty- Limited 2-year entire appliance Limited 5-year gas surface burners

    Labor Warranty- Limited 2-year entire appliance

    Warranty Notes- See written warranty for full details
