Electrolux ECWM3012AS 30'' Wall Oven and Microwave Combination

Model: ECWM3012AS
  • Description
  • Features
  • Specifications
  • The Electrolux Connected Wall Oven and Microwave is designed to inspire culinary creativity. Packed with advanced technologies like Air Sous Vide, Steam cooking modes, Built-In Air Fry and Advanced Convection
  • Air Sous Vide Technology
    Preserve natural flavors & lock in moisture with our Air Sous Vide technology that uses precisely-controlled heat and airflow to give you sous vide results without the water bath
    Steam Bake & Steam Roast
    Enhance natural flavors - from meats to pastries and more - by creating a crisp, golden crust and a juicy, flavorful inside with the power of steam
    Electrolux Connect Technology
    Cooking is more effortless with Electrolux Connect Technology, which allows you to set, preheat and monitor cook time remotely. When cook time ends, get alerts and even switch to “keep warm” mode to ensure dishes are all ready at the same time
    Built-In Air Fry
    Create crispy vegetable chips, juicy chicken parmesan and more with just a little oil with Built-In Air Fry
  • Dimensions and Volume

    Height: 41 9/16"

    Width: 28 7/8"

    Depth: 25 3/16"

    Depth With Door 90° Open: 47 3/16"

    Depth With Handle: 27 3/5"

    Cutout Depth: 23 5/8"

    Oven Interior Height: 18 1/8"

    Oven Interior Width: 25 3/16"

    Oven Interior Depth: 19 7/8"

    Microwave Interior Height: 9 5/16"

    Microwave Interior Width: 18 7/8"

    Minimum Cutout Height: 40 5/8"

    Microwave Interior Depth: 16 1/8"

    Minimum Cutout Width: 28 1/2"

    Maximum Cutout Height: 41 1/2"

    Maximum Cutout Width: 29"

    Microwave Capacity: 1.7 Cu. Ft.

    Oven Capacity: 5.3 Cu. Ft.

    Internal Specifications

    Rack: Yes

    Turntable Diameter: 14"

    Turntable Material: Glass


    Control Location: Front

    Display Interface Color: White

    Display Light Color: White

    Display Type: Capacitive Touch

    General Specifications

    Product Weight: 245 lbs

    Prop 65 Label: Yes

    Warranty - Labor: 1 Year

    Warranty - Parts: 1 Year


    Wi-Fi Enabled: Yes


    Control Lock: Yes

    Sabbath Mode: Yes

    Cooking Controls

    Air Fry: Yes

    Air Sous Vide: Yes

    Bake: Yes

    Bake Time: Yes

    Bread Proof: Yes

    Broil: Yes

    Cancel: Yes

    Child Lock: Yes

    Clear Off: Yes

    Clock: Yes

    Convection Bake: Yes

    Convection Roast: Yes

    Cook Time: Yes

    Dehydrate: Yes

    Delay Clean: Yes

    Delay Start: Yes

    Fast Preheat: Yes

    Keep Warm: Yes

    Kitchen Timer: Yes

    Light: Yes

    My Favorite: Yes

    Off: Yes

    Oven Light: Yes

    Perfect Turkey: Yes

    Preheat: Yes

    Probe: Yes

    Self Clean: Yes

    Set Clock: Yes

    Slow Cook: Yes

    Start: Yes

    Start Time: Yes

    Steam Bake: Yes

    Steam Clean: Yes

    Steam Roast: Yes

    Stop: Yes

    Temperature Display: Yes

    Timed Bake: Yes

    Timer On / Off: Yes

    User Preferences: Yes

    Electrical Specifications

    Amps @ 240 Volts: 40 Amps

    Connected Load @ 240V: 8.3 kW

    Minimum Circuit Required: 40 Amps

    Voltage Rating: 240 V

    Cooking Controls Function

    Change between Continuous Bake Setting or 12-Hour Energy Saving Feature: Yes

    Delayed Bake: Yes

    Program Fahrenheit or Celsius: Yes

    Silent Control Panel: Yes

    Timed Cooking: Yes

    Microwave Cooking

    Microwave Cooking Power: 1000 Watts

    Bacon: Yes

    Beverage: Yes

    Defrost: Yes

    Melt / Soften: Yes

    Popcorn: Yes

    Reheat: Yes

    Rice: Yes

    Top Grill Mode: Yes

    Veggies: Yes


    Bake Element: 2,500 Watts

    Bake Element Pass: 8

    Bake Element Type: Hidden

    Broil Element: 4,000 Watts

    Broil Element Pass: 6

    Broil System: Yes

    Cleaning System: Yes

    Convection: Yes

    Convection Element: 3,800 Watts

    Convection Type: Total

    Number of Convection Fans: 1

    Number of Rack Positions: 6

    Oven Interior Color: Midnight Black

    Oven Light Quantity: 2

    Oven Light Type: Halogen

    Oven Light Watts: 40 Watts

    Rack Position Type: Embossed

    Rack Type 1: Handle Bull Nose

    Rack Type 1 Quantity: 1

    Rack Type 2: Glide

    Rack Type 2 Quantity: 1

    Rack Type 3: Air Fry Tray

    Rack Type 3 Quantity: 1


    Power Supply Connection Location: Top Left

    Microwave Control Features

    + 30 Seconds: Yes - One Touch

    Certifications and Approvals

    ADA Compliant: No

    Star-K Certification: Yes

    CSA Listed: Yes

    UL Listed: Yes

    RoHS: Yes

    Convection Cooking

    Convection Cooking - Bake: Yes

    Convection Element: 1650 Watts
